Viser både in.lb. - ft.lb. - Nm
Square Drive, inches 1/4
Head Type Sealed Flex Head
Gear Teeth 36
Gear Action 10°
Range, in. lb. 24-240
Range, ft. lb. 2-20
Range, Nm 2.7-27.12
Head Depth, inches 7/16
Head Width, inches 7/8
Operating Temperature 40-110°F (5-42°C)
Storage Temperature 0 to 122°F (-20 to 50°C)
Humidity up to 90% non-condensing
Housing Color Red
Ratchet Service Kit RKRT936
Length, inches 15 1/4
TECHWRENCH® FEATURES
Accuracy (Ratchet Models) 2%CW, 3% CCW.
Each button has ONLY one function (power on, select unit of measure, increase fastener torque setting, decrease fastener torque setting).
All models include 3 "AA" batteries for power.
Comfortable, non-slip grip handle.
Stand on handle bottom keeps tool from rolling off flat surface.
Flex-head ratchet moves 15°.
All models have a Low Battery Indicator and Auto Shut-off (after 2 minutes idle).
Designed to withstand shocks without failure.
Splash-proof, protects against water and most automotive shop fluid.
Complies with ISO-6789-2003 and ASME B107-28-2005 Standards.
EU/CE-DE, ES, FR, IT, NL, PT, UK.
Includes storage case.
Additional technical information is available at www.snapon.com/torque/techwrench.
Note:
The certification of accuracy provided per ASME and ISO Standards is 20% to 100% of full scale. For more information, go to www.snapon.com/torque/Techwrench.
Note:
The certification of accuracy provided per ASME and ISO Standards is 20% to 100% of full scale.
Square Drive, inches 1/4
Head Type Sealed Flex Head
Gear Teeth 36
Gear Action 10°
Range, in. lb. 24-240
Range, ft. lb. 2-20
Range, Nm 2.7-27.12
Head Depth, inches 7/16
Head Width, inches 7/8
Operating Temperature 40-110°F (5-42°C)
Storage Temperature 0 to 122°F (-20 to 50°C)
Humidity up to 90% non-condensing
Housing Color Red
Ratchet Service Kit RKRT936
Length, inches 15 1/4
TECHWRENCH® FEATURES
Accuracy (Ratchet Models) 2%CW, 3% CCW.
Each button has ONLY one function (power on, select unit of measure, increase fastener torque setting, decrease fastener torque setting).
All models include 3 "AA" batteries for power.
Comfortable, non-slip grip handle.
Stand on handle bottom keeps tool from rolling off flat surface.
Flex-head ratchet moves 15°.
All models have a Low Battery Indicator and Auto Shut-off (after 2 minutes idle).
Designed to withstand shocks without failure.
Splash-proof, protects against water and most automotive shop fluid.
Complies with ISO-6789-2003 and ASME B107-28-2005 Standards.
EU/CE-DE, ES, FR, IT, NL, PT, UK.
Includes storage case.
Additional technical information is available at www.snapon.com/torque/techwrench.
Note:
The certification of accuracy provided per ASME and ISO Standards is 20% to 100% of full scale. For more information, go to www.snapon.com/torque/Techwrench.
Note:
The certification of accuracy provided per ASME and ISO Standards is 20% to 100% of full scale.
