Følgende er inklusiv:
2 Amp Ceramic, UL Fuse (EEDM503B2)
10 Amp Ceramic, UL Fuse (EEDM504B2)
Test Lead Set with Alligator Clips (EEDM504B3)
Rubber Boot (EEDM504D1)
Soft Pouch (EEDM504B4)
Instruction Manual (ZEEDM503D)
9-volt Battery
Optional Accessories (Not Included)
0-400 AC/DC Amp Clamp-on Accessory (EETA501B)
0-1,000 AC/DC Amp Clamp-on Accessory (EETA502B)
10mA to 60Amp Low Current Clamp (MT10100)
30 Amp Adaptor (MT5030)
0 - 500PSI Pressure Adaptor (MT5810)
Boot Hook Hanger for Rubber Boot (EEDM503B1)
RPM Adaptor (MTRMPGA)
Hard Carrying Case (MT586BK1)
Soft Carrying Case with shoulder strap (MT596AK1)
K-Type Differential Temperature Adaptor (EEDM506C)
Coiled Cord Test Lead Set (TL2A)
Deluxe Test Lead and Adapter Set (MTTL700)
General Specifications
Max. Voltage between any Input and Ground: 1000V
Fuse Protection mA: 2Amp/600VAC
Fuse Protection A: 10Amp/600VAC
Display Type: 2000 Count
Operating Temperature: -0° to 40°C (32° to 104°F)
Storage Temperature: -10° to 50°C (14° to 122°F)
Relative Humidity: 0% to 80%
Power Supply: 9 Volt Battery
Battery Life: 560 hrs. Alkaline
Size (H x L x W): 1.5" x 3.75" x 7.7" (38.1mm x 95.25mm x196.85mm)
Weight: 24 oz. (680 grams)
Features:
LCD DISPLAY - Large, Easy-to-read, 2000 count LCD display.
ON/OFF PUSH BUTTON - Push to turn the EEDM503C on and off.
OHM - Measure Ohms to determine resistance of a coil or spark plug wire.
CONTINUITY BUZZER - Test continuity of fuses, fusible links, components and circuits.
DIODE TEST - Use the diode function to test the diode pack on a typical alternator.
DC AMPS - Measure DC current to determine the presence of a parasitic load. Measure current draw of branch circuits.
DATA-H (Data Hold) - Lock reading on the display in hard to read locations or for future reference.
DC VOLTS - Use DC voltage to verify if the proper voltage level is arriving at a sensor of circuit.
AC VOLTS - Measure AC voltage signals on digital MAF sensors, wheel speed sensors and vehicle speed sensors.
AC AMPS - Measure the current draw of AC powered equipment in the shop.
TILT STAND - Is built-in into the instrument housing.
SEPARATE FUSE/BATTERY COMPARTMENT - Is easily removed for battery/fuse replacement. Fuses are labeled with replacement number.
