Følgende er inkluderet :
500mA, Ceramic UL Fuse (EEDM504B1)
10 Amp Ceramic, UL Fuse (EEDM504B2)
Test Lead Set with Alligator Clips (EEDM504B3)
Temperature Input Adaptor (MT586-4)
Temperature Probe (MT586-14)
Software and Cable (EEDM596D1)
Inductive Pick-up (EEDM512B1)
Rubber Boot (EEDM504D1)
Soft Carrying Case (MT596AK1)
Instruction Manual (ZEEDM596D)
Optional Accessories (Not Included)
0-400 AC/DC Amp Clamp-on Acc (EETA501B)
0-1,000 AC/DC Amp Clamp-on Acc (EETA502B)
10mA 60 Amp Low Current Clamp (MT10100)
30 Amp Adaptor (MT5030)
0 - 500PSI Pressure Adaptor (MT5810)
Boot Hook Hanger for Rubber Boot (EEDM503B1)
Hard Carrying Case (MT586BK1)
Deluxe Test Lead Set and Adapters (MTTL700)
General Specifications
Max. Voltage Between any Input and Ground: 1000V
Fuse Protection mA: 0.5Amp/600VAC
Fuse Protection: A: 10Amp/600VAC
Display Type (digital): 40,000 Count 4x per second update (analog): 2 x 41 segments, 20 x per second update
Operating Temperature: -0° to 45°C (32° to 113°F)
Storage Temperature: -40° to 60°C (-40 to 140°F)
Relative Humidity: 0% to 80%: (0° - 35°C/32° - 95°F) 0% to 70%: (35° - 55°C/95° - 131°F)
Temperature Coefficient: 0.1x (Specified Accuracy per °C for temperature <18°C to >28°C)
Power Supply: 9 Volt Battery
Battery Life: 100 hours Alkaline
Size (H x L x W): 1.5" x 3.75" x 7.75" (38.1mm x 95.25mm x 196.85mm)
Weight: 24 oz. ( 680g)
Features:
LCD Display - 40000 count with 42 segment bar graph.
REC (Record Mode) - Store minimum, maximum, and average readings over a measurement period.
RANGE - Manually select the appropriate range.
AC/DC - Manually select AC or DC measurement function.
FUNCTION - Toggle between functions on Ohm, TEMP, and IG modes.
Hz (Frequency) - Measure the frequency of sensors and signals.
OHMS/RESISTANCE - Measure the resistance of spark plug wires, coils, sensors, and continuity of wiring.
High Resolution DCmV Range - Additional 40 millivolt range with 0.01mV resolution for improved accuracy when performing low voltage measurements.
DCV, ACV (DC Volts, AC Volts) - Measure the voltage of circuits and sensors. Measure the voltage of ABS wheel sensors.
REL (Relative Mode) - Factor out lead resistance for improved low ohm measurements or compare readings to a known standard. Can also be used for differential measurements.
CYL (Cylinder) - Selects the number of cylinders in IG mode.
HOLD - Lock the reading on the display for hard to read locations for future reference.
PEAK-H (Peak Hold) - Capture signals spikes as fast as 1mS to diagnose intermittent events.
TEMP (Temperature) - Measure temperature with included temperature probe.
AC/DC Current Functions - Measure the parasitic draw from the battery with ignition off.
CAPACITANCE - Measure the capacitance of condensors or capacitors found in today's hybrid automobiles.
IP, IG (Automotive Functions) - Measure RPM, Duty, Dwell, mS pulse width, Frequency.
TILT STAND - Is built directly into instrument housing.
SEPARATE FUSE/BATTERY COMPARTMENT - Is easily removed for battery and fuse replacement. Fuses are labeled with replacement number.
